PC2700 Power Amplifier

Name: PC2700 Power Amplifier
Brand: Guangzhou DSPPA Audio Co., Ltd.

Features

● Transformers isolated 70V, 100V & 4~16 Ω speaker output,
● DC24V,Rated power 650W
● LCD display, clear status indication
● XLR socket and 6.3mm jack for additional mixer or amplifier link
● Output short circuit protection & alarm
● Provide data communication with Pc10 series rack system
● Remote control through management software
● Series amplifier of high output power available
● Short-circuit,over-current,over-load,over-heat warning and protection,distortion indication

Contact now Leave message Download

Introduction
Specification
Connection

This amplifier is designed for commercial and industrial public address applications. Rack mount design in 2U type and rated power is 650W.
Both balanced and unbalanced line inputs for each channel make it selectable for installer, balanced line output feeds to another power amplifier as well as secures the signal transmission is less noise and longer distance. 70V, 100V and 4 Ohm speaker outputs are convenient for installation when selection different speaker matching. A master volume control is included. Complete protection includes clip, short circuit, high temp and overload. Indications for power, signal, clip, protection and temp.

Model	PC2700
Rated power	650W
Rated output voltage	70V/100V/4-16 ohm
Inputsensitivity	0dB
S/N Ratio	> 85dB
THD into 4W/1kHz	<0.3%
Frequency response	100Hz ~20kHz (±3dB)
Indicators	Power,clip,signal,Prot,and TEMP
Protection	Power turn on/turn off,Overheating,DC voltage&Short Circut
Powerrequirement	DC24V/ AC220~240V/50~60Hz
Unit Size (mm)	(L×W×H)483´380x88
Netweight	22.5Kg
Gross weight	25Kg
