The 2 channel power amplifiers are designed for commercial and industrial public address applications. With two separate amplifiers in a single chassis and rated power is 350W. The amplifier is design of rack mount type and its 2U height.
The Amplifier can be exchanged control signal and status information with MAG host. This product can be called dual channel amplifier or dual channel amp.
Both balanced and unbalanced line inputs are available for each channel. 70V, 100V and 200V outputs for each channel are convenient when installation and can be matched with different speakers. Individual volume and tone control function for each channel are ensured. Complete protection from over heat, over load, clip & short circuit. With indications for power, signal, clip, protection and Temp.
|
Model |
MAG1335II |
|
Rated power |
350 W |
|
Rated output voltage |
70V/100V/200V |
|
Inputsensitivity |
0dBu |
|
S/N |
≥80dB |
|
Regulation ratio |
≤3dB |
|
Frequency response |
70Hz ~16kHz (±3dB) |
|
Tone |
100Hz (±10dB); 10kHz (±10dB) |
|
Power Consumption |
600 W |
|
Powerrequirement |
AC220~240V/50~60Hz |
|
Unit Size (mm) |
(L×W×H)88´483´443 |
|
Netweight |
26 Kg |
