MAG6421 One Key Emergency Network Intercom Terminal

Features

● Built-in 3W speaker and microphone
● Built-in 2*10W digital amplifier
● Support POE and DC power supply
● Support SIP/VOIP protocol, realize two-way intercom
● With 1 alarm input and 1 alarm output
● Standard RJ45 interface, across network segments and routes
● Comply with IP65 protection level
● Can play background music, scheduled broadcasts, emergency paging, alarm signals and others from the system host

  • Introduction
  • Specification

The voice and video intercom terminal uses a professional audio and video processing chip and runs an embedded Linux operating system, which is stable and reliable. It can realize functions such as calling the police/(visual) intercom for help in emergency situations. The product has 1 alarm input, which can be connected to external alarm linkage equipment; it has 1 alarm output, which can linkage control other equipment. The appearance is simple, and the screw-invisible design makes the panel more beautiful without any screws visible; it has high work efficiency, complies with the IP65 waterproof level, which can be used in a variety of outdoor occasions.


Item

MAG6421

MAG6422

MAG6441

MAG6442

AUX IN

Input Sensitivity

300mV±50mV

Frequency Response

40Hz-16kHz(±3dB)

Distortion

≤0.7%

SNR

≥75dB

Network Amplifier

Input Sensitivity

-10dB

Frequency Response

40Hz-16kHz(±3dB)

Distortion

≤0.7%

SNR

≥75dB

Maximum Output Power of External Power Amplifier

DC Power Supply Mode

2*20W/ 4Ω

PoE Power Supply Mode

2*10W/ 8Ω

Maximum Harmonic Distortion of External Power Amplifier

≤1%

Built-in Speaker

3W/4Ω

Power Supply Range (DC)

15V

Overcurrent, Overheating, Overvoltage, Undervoltage Protection

Support

Package Size (L×W×H mm)

265*245*80mm

285*245*80mm

Product Size (L×W×H mm)

194*115*54mm

214*115*54mm

Gross Weight

1.5kg

1.6kg

Net Weight

0.9kg

1kg
