MAG6364G Network Indoor Speaker with 2.4G Bluetooth

Name: MAG6364G Network Indoor Speaker with 2.4G Bluetooth
Brand: Guangzhou DSPPA Audio Co., Ltd.


Features

● With integrated design of networked terminal processor and high fidelity speaker.
● With dual network interface redundant design, can work across network segments.
● Can be applied at any place with access to network.
● With MP3 decoding playback function.
● Supports 16-bit digital audio stream decoding with a maximum sampling rate of 48kHz.
● Built-in 2×20W digital amplifier, low power consumption settings.
● Can play background music, emergency paging, alarm signals, and others from the system host.
● With one auxiliary audio input port,one auxiliary audio output port, one microphone input and one EMC emergency output, one short-circuit output.
● Controllable local output volume and local playing state.
● Digital display of working state and information change.
● It can be controlled by the infrared remote controller.
● 2.4G wireless microphone broadcasting: used with 2.4G wireless microphone, mainly applied to wireless multimedia teaching.
● Bluetooth music broadcasting: It can accept the Bluetooth signal of the mobile phone for Bluetooth music broadcasting.

Contact now Leave message Download

Introduction
Specification

MAG6364G Network Indoor Speaker with 2.4G Bluetooth is a modern network playback terminal based on TCP/IP transmission protocol, which has a fully digital analog-to-digital conversion signal processor combined with high-fidelity speakers to realize the integrated design of the processor and the speaker. With dual network redundancy design, and can be applied at any place with access to the network. The remote audio data stream can output the audio signal through the machine, and directly send sound from the speaker with intelligent control of the host machine; MP3 program can be played when the network audio stream signal is not played; There is an auxiliary audio input interface for connecting other audio source devices (such as DVD player), and an auxiliary audio output interface for connecting other amplifiers to expand power.It has a built-in 2.4G transmission mode and a transmission box with a microphone, which mainly realizes 2.4G broadcasting function and can be used for local broadcasting, wireless multimedia teaching, wireless conference, etc.

Model		MAG6364G
Network Indoor Speaker
AUX IN	Input Sensitivity	300 mV
	Frequency Response	20Hz-20kHz
	Distortion	≤0.5%
	SNR	≥75dB
AUX OUT	Rated Output	1000mV
	Frequency Response	20Hz-20kHz
	SNR	≥75dB
MIC Microphone Interface	Input Sensitivity	4 mV
	Frequency Response	50Hz-16kHz
	Distortion	≤0.5%
	SNR	≥70dB
USB/SD /NET Play MP3 Music	Frequency Response	20Hz-18kHz
	Distortion	≤0.5%
	SNR	≥75dB
SD Card Capacity		32GB
USB Capacity		32GB
Power Supply		AC220V/50Hz
Display Screen		Digital Screen
Wireless 2.4G Microphone
Wireless MIC Input Sensitivity	140mV±10mV
THD	0.5%
Frequency Characteristic	80Hz～5KHz(-3dB)
Wireless AUX Input Sensitivity	600mV±10mV
THD	0.5%
Frequency Characteristic	80Hz～12KHz(-3dB)
BT Input Sensitivity	-10dB
THD	1%
Frequency Characteristic	70Hz～8KHz(-3dB)
Transmission Reception Distance	≥10m
SNR	≥70dB
Frequency Pairing Method	Automatic frequency pairing, automatic frequency hopping, automatic frequency locking, 1 to 1 matching.
Matching Distance	It has been set to within 3 meters, and the matching distance can be modified by operating the microphone
Package Size (L×W×H mm)	405×405×275mm
Machine Size (L×W×H mm)	330×200×150mm
Gross Weight (2PCS)	12kg
Net Weight	5.3kg
