DMA60M 6 Zones Remote Paging Station

Features

● With independent zone switches for quick control of the 6 zones of the amplifier.
● With signal level indication function for more intuitive paging volume.
● With key lock function.
● One chime tone with a descending tone.
● With dual RJ45 interfaces for zone control and override functions. When cascading paging stations with a single port, the mixer amplifier can support up to 6 paging stations on a single port, with a maximum transmission distance of 300m. If only one paging station is connected to the mixer amplifier, the transmission distance can be up to 600m. The paging microphone does not require a separate power adapter and it is powered and receives audio transmission from the DMA series 6-zone amplifier. Note: Each host supports a maximum of 6 remote paging microphones.
● With 1-channel microphone volume adjustment.
● With one-touch all-zone paging function.
● With anti-fingerprint coating for the touch panel.

  • Introduction
  • Specification

Working with DMA6112/DMA6124.

Model

DMA60M

Sensitivity

30±3mV

Frequency Response

200Hz-15KHz

S/N Ratio

≥70db

RJ45 Connector

RS485 communication protocol

Input Power

Powered by the host

Package Dimensions (H×W×D)

425×285×115mm

Machine Dimensions (H×W×D)

172×160×53mm

Gross Weight

1.6KG

Net Weight

0.89KG
