DSP0810 8'' 100W Outdoor Waterproof Horn Speaker

Features

● Driver Unit: 8"×1, 1.5"×1, Rated Power 100W
● Signal Input:100V or 8Ω
● Frequency Response:110Hz-16KHz
● Sensitivity(1W/1M):96+3dB
● Max. SPL:116+3dB
● Coverage Angle:50x70
● Connector:2×Neutrik SpeakonNL4
● Product Size: 300×300×310mm
● Product Weight: 11kg
● Waterproof level: IP56

  • Introduction
  • Specification

The DSP0810 is a high-power long-range horn speaker with a coaxial design for treble and bass, featuring professional-grade coaxial drivers. It features efficient sound transmission, strong penetration, and high speech intelligibility. The enclosure is made of PP material, offering waterproof, corrosion-resistant properties, making it suitable for various extreme climates and environments. This product is widely used in stadiums, schools, training grounds, air raid warning systems, coastal beaches, and highways.



Model

DSP0810

Speaker Unit

8"×1, 1.5"×1

Rated Power

100W

Input

100V/8Ω

Frequency Response

110Hz-16KHz

Sensitivity (1W/1M)

96+3dB

Max. SPL (1M)

116+3dB

Coverage Angle

50×70

Waterproof level

IP56

Color

Black/Grey

Product Weight

11kg

Product Size

300×300×310mm
