MA2250U 2*250W Multimedia Mosque Amplifier
Features
● 70V/100V & 4-16Ω speaker output
● Rated power: 2*250W
● Separate 2 channels output control of Volume/Echo/Bass/Treble
● Built-in 3 Mic and 1 AUX and USB/Bluetooth, 1 Chimes, 1 AUX output
● Combo for Mic1,XLR for Mic2 - Mic3, with phantom power 48V
● Individual volume control for Mic1-3 and Aux input
● Priority: Chime=MIC1-3>AUX/Bluetooth/USB
● Protection: Overload, Clipping, Short circuit and temperature protection
● With 19" rack mount handles
● Power supply: AC220V-230V/50/60Hz
- Introduction
- Specification
Model
|
MA2250U
|
Rated Power
|
2×250W
|
Output Interface
|
Barrier Terminal Block
|
AUX Input Sensitivity
|
350MV
|
MIC Input Sensitivity
|
20kΩ/Balanced, 10kΩ/ unbalanced
|
SNR
|
≥75dB
|
Tone Adjustment
|
Bass:±10dBTreble:±10dB
|
Frequency Response
|
45Hz-20kHz(±1dB)
|
Distortion
|
<0.1%@1KHz
|
Power Supply
|
AC220-240V/50Hz
|
Protection
|
Load short circuit, DC output, power on/off, over temperature
|
Power Consumption
|
700W
|
Machine Size
|
(L×W×H)484×412×90mm
|
Package Size
|
(L×W×H)535×470×165mm
|
Net Weight
|
16.0kg
|
Gross Weight
|
16.8kg
|
